產品規格型號 |
額定蒸發量 KW |
額定蒸汽 壓力MPa |
飽和蒸汽 溫度℃ |
額定給水 溫度℃ |
熱效率 % |
最大件 運輸重量t |
外形尺寸 (長x寬x高)mm |
配電功率 KW |
LDR0.05-0.7 |
30 | 0.7 | 170 | 20 | 95 | 1000 | 1200x900x1350 | 35 |
LDR0.1-0.7 |
40 | 0.7 | 170 | 20 | 95 | 1100 | 1300x1000x1550 | 45 |
LDR0.2-0.7 |
70 | 0.7 | 170 | 20 | 95 | 1300 | 1500x1200x1865 | 80 |
LDR0.3-0.7 |
140 | 0.7 | 170 | 20 | 95 | 1400 | 1500x1200x2050 | 160 |
LDR0.4-0.7 |
210 | 0.7 | 170 | 20 | 95 | 1500 | 1500x1200x2250 | 250 |
WDR0.5-1.0 |
280 | 1.0 | 180 | 20 | 95 | 2000 | 2100x1540x1450 | 320 |
WDR0.6-1.0 |
350 | 1.0 | 180 | 20 | 95 | 2100 | 2280x1540x1450 | 400 |
WDR0.7-1.0 |
500 | 1.0 | 180 | 20 | 95 | 2300 | 2640x1540x1450 | 550 |
WDR0.8-1.0 |
600 | 1.0 | 180 | 20 | 95 | 2400 | 2750x1600x1550 | 660 |
WDR1.0-1.0 | 700 | 1.0 | 180 | 20 | 95 | 2500 | 3110x1600x1550 | 780 |
產品規格型號 |
額定蒸發量 KW |
額定蒸汽 壓力MPa |
飽和蒸汽 溫度℃ |
額定給水 溫度℃ |
熱效率 % |
最大件 運輸重量t |
外形尺寸 (長x寬x高)mm |
配電功率 KW |
CWDR0.03-85/60 |
30 | 常壓 | 85 | 60 | 95 | 600 | 1000x500x1000 | 35 |
CWDR0.04-85/60 |
40 | 常壓 | 85 | 60 | 95 | 700 | 1100x500x1100 | 45 |
CWDR0.07-85/60 |
70 | 常壓 | 85 | 60 | 95 | 800 | 1200x500x1200 | 80 |
CWDR0.14-85/60 |
140 | 常壓 | 85 | 60 | 95 | 950 | 1400x700x1400 | 160 |
CWDR0.21-85/60 |
210 | 常壓 | 85 | 60 | 95 | 1100 | 1400x900x1400 | 250 |
CWDR0.28-85/60 |
280 | 常壓 | 85 | 60 | 95 | 1300 | 1400x1200x1400 | 320 |
CWDR0.35-85/60 |
350 | 常壓 | 85 | 60 | 95 | 1500 | 1500x1500x1450 | 400 |
CWDR0.5-85/60 |
500 | 常壓 | 85 | 60 | 95 | 1800 | 1850x1500x1450 | 550 |
CWDR0.6-85/60 |
600 | 常壓 | 85 | 60 | 95 | 1900 | 1850x1600x1550 | 660 |
CWDR0.7-85/60 | 700 | 常壓 | 85 | 60 | 95 | 2000 | 2050x1600x1550 | 780 |
